Trujet U8KR
UV Printing Machines

Trujet U8KR

Print Speed 60 m²/h Print Speed
Print Width 320 cm Print Width

The Trujet U8KR Roll to Roll UV Printer is an ideal solution for high-speed and wide-format industrial production with a maximum print speed of 60 m²/h and a print width of 3.2 m.

DOWNLOAD CATALOGUE

Trujet U8KR Roll to Roll UV Printer


The high-precision aluminum platform and high-efficiency water-cooled LED UV lamps deliver exceptional stability and fast curing performance during printing. Equipped with a 3-level pinch roller system, industrial-grade negative pressure system, and carriage anti-collision system, it ensures continuous, safe, and high-quality results across all types of indoor and outdoor advertising and decoration materials.


Trujet U8KR Roll to Roll UV Printer
Model U8KR-32
Printhead Konica 1024i (6/13pl) / 8 Pcs
Print Speed / Mode 6 PASS: 60 m²/h (8 Heads)
Maximum Print Width 3.2 m (3200 mm)
UV Curing Lamp Equipped (High-efficiency water-cooled LED UV lamps)
Operating Temp / Humidity 20 – 26 °C / 40% – 70% RH
Power Machine Power: 1300W + UV Chiller: 2300W
RIP Software Ergosoft / NeoStampa / Photoprint / ONYX (Optional)
Media Type All kinds of indoor and outdoor advertising materials and decoration materials
Dimensions 4805 x 980 x 1560 mm (L x W x H)
Packing Dimensions 5120 x 1150 x 1650 mm (L x W x H)
Net / Gross Weight 1100 kg / 1370 kg
